Introduction
India’s design to make itself a global hub for semiconductor manufacturing has thrown the spotlight on to the industry, its investment potential, and technological capabilities. But what about the legal protection of the intellectual property embedded in a semiconductor chip? After all, the value of semiconductor chips derives from the way the multitude of transistors, circuits, and other devices are arranged and interconnected to perform the required functions. The manner in which they are connected is the subject of protection under what is termed a semiconductor integrated-circuit layout-design.
A semiconductor integrated-circuit layout-design enjoys the protection of the Semiconductor Integrated Circuits Layout-Design Act, 2000 (hereinafter the SICLD Act). However, the very fact that a dedicated act was required to protect this type of intellectual property suggests that other types of property rights, for example, patents, copyrights, and trademarks, do not offer the required level of protection. While a patent might protect the innovation behind a given technology, trademarks cannot provide the requisite level of protection for the ways in which a given technology is deployed or expressed. A copyright, on the other hand, may protect certain aspects of software or other expressions but typically has limited scope when it comes to protecting the actual technology. This is precisely why the SICLD Act grants special protection for layout-designs.
But if the SICLD Act provides the required level of protection, why has its registration regime seen only limited uptake? This article attempts to address this very question. It looks at the statutory framework, registration requirements, and the rights of registration holders under the SICLD Act. It also attempts to briefly highlight some of the possible reasons for the apparently low level of registrations.
SICLD Act, 2000 – Statutory Framework
The main challenge in protecting a semiconductor layout-design stems from the fact that such a design does not fall under any of the existing intellectual property categories. In other words, while a patent may be granted in relation to the technological innovation embodied in a particular integrated circuit (IC), and while copyright may protect design data or software, the layout-design itself is not protected by any of these forms of intellectual property. The Semiconductor Integrated Circuits Layout Design Act of 2000 (SICLD Act) was enacted in India to fill this lacuna, and it introduced a sui generis legal framework for the protection of semiconductor layout-designs.
The Act’s design falls into a clear-cut pattern. First of all, it is notable that not every design is eligible for protection. According to Section 2 of the Act, the term “layout-design” refers to the IC’s topology, which comprises transistor elements, as well as their location and interconnection scheme. Moreover, Section 7 stipulates that every layout-design must meet certain criteria to be eligible for registration. These include, in particular, requirements of originality and distinctiveness. Finally, Sections 8-15 outline the registration procedures, which a design must go through.
Registration, in turn, is the key to enjoying the benefits conferred by the Act. Indeed, it is established by Section 16 that no infringement suit may be brought against an unregistered layout-design. In other words, if the design is registered, then the owner may assert the exclusive rights granted by the Act, which are detailed in Sections 17 and 18, to sue for infringement. Moreover, Section 17 indicates the remedies available in cases of infringement.
As can be seen, the pattern of the Act is evident. However, it is important to keep in mind that, in order to assert the rights granted by the Act, the owner must first register the layout-design. In this regard, it is the registration process and the very possibility of passing the eligibility test that appear to be the critical link in the chain of “eligibility – registration – rights – remedies.” Therefore, the practical relevance and effectiveness of the SICLD Act may be evaluated in terms of whether its registration rules provide designers with sufficient benefits in terms of protecting their original designs.
Registration Process of a Layout Design under the SICLD Act, 2000
Protection under the SICLD Act does not arise automatically upon creation of a semiconductor layout-design by its creator. The creator needs to go through a statutory registration process, making registration the exclusive channel for obtaining protection.
The process can be summarized in five steps: Application, Formal examination, Examination, Advertisement and Opposition, and Registration.
Application
The applicant submits Form LD-1 along with the prescribed fee, together with a description of the layout-design and either drawings or photographs of masks or the GDS-II file with PDK information.
Formal examination
The application is checked by the Registry for compliance with the required formalities, including the submitted documents, fee, and other requirements.
Examination
The Registry then examines the layout-design for registrability, including determining whether it is original.
Advertisement and Opposition
The application is advertised, and any person who is opposed to the registration of the layout-design can file a notice of opposition within three (3) months from the date of advertisement, or within an additional month in case of an extension.
Registration
The layout-design is entered into the Register by the Registrar if no opposition is filed or if the opposition is resolved against the opponent.
What constitutes an “original” Layout design under the Section 7 of SICLD Act
The more interesting question is what constitutes “original” in Section 7. The SICLD Act states that in order to be registered, a layout-design must have been created by the creator or designer of the semiconductor, and that it must not be commonplace among creators or manufacturers of semiconductors. One can easily sense the dilemma that Section 7 presents to would-be registrants. After all, in order to design a semiconductor, one has to use standard components, architectures, and design elements. By the same token, the law recognizes independent creation as a defense to infringement. The real question is how much intellectual effort goes into the design of a semiconductor for it to qualify as an “original” layout-design under the SICLD Act.
Rights, Term of Protection and Remedies for Infringement
Registration of qualifying layout-designs under the SICLD Act, 2000 conveys a particular intellectual-property right to the proprietor. The importance of this right is limited by the practical possibility for the proprietor to identify and prove infringement of that right.
A. Rights of the Registered Proprietor
Section 17 of the SICLD Act grants copyright-like rights to the proprietor of a registered layout-design and provides that such a proprietor may seek remedies available for copyright infringement. Section 18 defines infringement, which comprises unauthorized reproduction and adaptation of the protected layout-design, its incorporation into another integrated circuit and various forms and modes of dealing with such integrated circuits (including importation, sale, distribution).
B. Term of Protection
As per Section 15 of the SICLD Act, the term of protection is ten years from the date of filing of the application or from the date of first commercial exploitation of the layout design, whichever is earlier, provided that other requirements of the SICLD Act are met. This provision raises the conceptual issue of whether such a period is not too short, given the tendency of semiconductor technologies to become outdated within a decade. On the other hand, an extended period of protection may be considered unduly lengthy for a rapidly evolving technological innovation.
C. Infringement and Remedies
The SICLD Act, 2000 contains a civil cause of action for infringement of layout-design copyrights with remedies that include injunction, damages or an account of profits and other appropriate relief available for copyright infringement. At the same time, Section 18(8) of the SICLD Act, 2000 provides that copyright in an independently created layout-design is not infringed by another layout-design that is substantially similar to the former. This section raises the critical question of how a proprietor of the first layout-design can prove that the independently created second layout-design was in fact copied from the first. The problem with proof of copying in semiconductor design copyright infringement is that the allegedly copied design may not be publicly available and the similarity of layout-designs may be the result of independent development. Similar issues arise in litigation concerning similarities of photographs or trademarks, but in the case of layout-designs the technical complexity of semiconductor technologies may require extensive technical analysis to prove infringement. Thus, although the SICLD Act, 2000 gives a copyright-like protection to the layout-designs and provides remedies available in copyright infringement cases, the ability of the proprietor to actually bring a successful infringement action is contingent upon the ability to technically prove that a particular semiconductor layout was copied from another one. In this respect, the SICLD Act, 2000 raises more questions than answers.
Why is the SICLD Registry Under-used?
The most surprising aspect of India’s semiconductor layout-design law is not what the law says, but rather the practice surrounding its adoption. The SICLD Registry’s Statistics as available in the CGPDTM’s Annual Report 2024-25 reveals that only 31 applications have been lodged since the SICLD Act came into force. Of these, 15 have been examined, i.e., 7 registered and 8 rejected or abandoned, leaving 16 applications still pending, including 6 filed in 2024-25 alone. Therefore, rather than asking why India has failed to protect its semiconductor designers, perhaps the more interesting question is why the law is apparently not being used at all.
There are several possible explanations for the deceptively low numbers:
- Disclosure versus Secrecy: An applicant for registration must disclose either representations or technical information concerning the layout-design, and therefore the potential commercial value of the design is necessarily divulged. By way of contrast, there is no requirement for patent or trademark registration of a semiconductor design, and accordingly, a commercial design of significant value may be kept secret, as confidentiality typically grants better legal protection than registration. It is a dilemma common to all intellectual property systems, disclosure for the sake of statutory protection, or secrecy for the sake of commercial advantage?
- Length of Protection: The value of any semiconductor design is necessarily limited by rapid technological development in the field, and therefore although the SICLD Act provides for a generous period of protection (10 years), it is unclear how worthwhile it would be for a company to apply for registration of a design that is likely to become technologically obsolete within the same period.
- Specialised Nature of the Right: Compared to patents and trademarks, semiconductor layout-designs are a specialised area of intellectual property, and there is accordingly little appetite for their registration.
- Enforcement Challenges: The registration of a semiconductor layout-design is of limited value if infringement cannot readily be identified or proven. Infringement of a registered layout-design is notoriously difficult to prove because, although simple copying can easily be shown, independent design of a similar layout-design is often difficult to establish.
- Availability of Alternative Forms of Protection: Most significantly, semiconductor design companies are able to avail themselves of alternative forms of intellectual property, such as patents, trade secrets, and confidentiality undertakings, and accordingly, there is little incentive to pursue registration of layout-designs.
Therefore, while the low rate of registrations under the SICLD Act certainly raises questions about the relevance of the Act, it is premature to dismiss the potential value of the scheme, and instead companies considering protection of their semiconductor designs would be well-advised to consider carefully the potential commercial advantages offered by each of the various forms of available protection. India’s stated desire to become a global leader in semiconductor design means that questions concerning the desirability of the current SICLD Act will grow in importance in the coming years.
Conclusion
The SICLD Act, 2000 provides India with a specialised legal framework to protect one particular aspect of semiconductor innovations which is not covered by traditional intellectual-property rights, namely, the integrated-circuit layout-design. By providing for its own registration regime, originality test, exclusive rights and remedies against infringement, India has demonstrated its understanding of the need to offer protection for this distinct form of intellectual property.
Yet, the very fact that the SICLD Registry sees only occasional applications raises the question: is a statutory right always attractive or useful? The need for registration, the possibility of conflicting rights, the onerous proof of originality and copying, the issue of disclosure, the rapid technological progress in semiconductors, and the existence of other forms of intellectual-property protection, all these factors may vitiate the desirability of such a protection regime.
Thus, while the SICLD Act, 2000 undoubtedly grants intellectual-property rights, the more interesting question is whether this form of intellectual property is suited to contemporary realities. If India wishes to become a semiconductor power on a par with leading semiconductor nations, it must think through the implications of its legal framework for semiconductor development. Enhanced awareness, improved registration practices, and simplified dispute-resolution mechanisms in infringement cases would make the regime more attractive.
After all, building semiconductor capabilities is one thing; protecting their intellectual underpinnings is another, and both are essential if India is to become a semiconductor power.
